3 In 3 Out Fiber Optic Splice Closure , PC In Line Underground Outdoor Fiber Enclosure

3 In 3 Out Fiber Optic Splice Closure , PC In Line Underground Outdoor Fiber Enclosure

  • High Light

    fiber optic splice enclosure

    ,

    outdoor splice box

  • Capacity
    Bunchy: 96 (Cores) ;Ribbon: 144(Cores)
  • Material
    PC
  • Cable Port
    3in 3out
  • Color
    Black
  • Sealing
    Rubber Seal
  • Splice Tray
    4pcs
  • Dimension
    430x180x125 (mm)
  • Cable Diameter
    Φ8—Φ20 (mm)
  • Place of Origin
    china
  • Brand Name
    YINGDA
  • Certification
    ISO,SGS
  • Model Number
    H010
  • Minimum Order Quantity
    100 PCS
  • Price
    Negotiable
  • Packaging Details
    1pc / bag, 10pcs / carton box
  • Delivery Time
    5days after pay
  • Payment Terms
    T/T or western Union
  • Supply Ability
    50,000pcs per month

3 In 3 Out Fiber Optic Splice Closure , PC In Line Underground Outdoor Fiber Enclosure

Inline Splice Enclosure Distribution Box, 3in 3out PC In-Line Underground

Splice Closure H010





Description



This Installation Manual is suit for the Fiber Optic Splice Closure (Hereafter abbreviated as FOSC),

as the guidance of proper installation.



The scope of application is: aerial, underground, wall-mounting, duct-mounting, hand hole-mounting.

The ambient temperature ranges from -40℃ to +65℃.



Features

  1. Easy to re-enter and repair
  2. 3pcs cable entry and 3pcs cable exit ports
  3. Pressure testing valve and earth deriving device
  4. Intergrated seal, air tight and water proof
  5. RoHS compliant
  6. Can be used in through, branch or mid span splice locations



Application: aerial, underground duct or direct burial applications



Specification



Outside dimension (LxWxH)

430x180x125 (mm)

Weight (excluding outside box)

2500g-2825g

Number of inlet/outlet ports

3 (pieces) on each side (total 6 pieces)

Diameter of fiber cable

Φ8—Φ20 (mm)

Capacity of FOSC

Bunchy: 12—96 (Cores)

Ribbon: max. 144(Cores)

Splice tray capacity

Bunchy:12,24(cores) Ribbon:3 (pieces)



Specification



Name of accessories

Usage

Heat shrinkable

protective sleeve

Protecting fiber splices

Nylon tie

Fixing fiber with protective coat

Insulation tape

Enlarging diameter of fiber  cable for easy fixing

Seal tape

Enlarging diameter of fiber  cable which fits in with seal fitting

Hanging hook

For aerial use

Earthing wire

Putting through between earthing devices

Abrasive cloth

Scratching fiber cable

Labeling paper

Labeling fiber

Special wrench

Fixing bolts, tightening nut of reinforced core

Measuring paper

To measure circle, of which its diameter is enlarged with seal tape

Buffer tube



Hitched to fibers and fixed with FOST, managing buffer

Desiccant

Put into FOSC before sealing for desiccating air.





Package information

  1. 8pcs/carton
  2. Carton size:74*40*45cm
  3. G.W.:24KG
