LGX Module Fiber Optic Splitter Box Snap On 300 * 186.5 * 59mm For Bunchy Fibers

Basic Information
Place of Origin: CHINA
Brand Name: YINGDA
Certification: ISO
Model Number: GJS-2021
Minimum Order Quantity: 100pcs
Price: negotiable
Packaging Details: 1pc/box, 6pc/carton box
Delivery Time: 1week
Payment Terms: T/T, Western Union
Supply Ability: 100000pcs per month
Contact Now
Detail Information
Material: ABS Dimension: 300*186.5*59mm
Cable Port: 2in 2out Drop Cable Port: 8pcs At Both Ends For 2x3mm
Cable Diameter: Φ8~Φ13mm Feature: Snap On, Clip Lock
Splitter Type: LGX Module With Micro Splitter Splitter Ratio: 1x8 Plc Splitter
Max Fusion: 24 Fibers / Cores

Product Description

New FTTH Drop Cable Fiber Optic Splice Closure for 1x8 Splitter Box LGX 2in 2out





GJS-2021 Splitting and Wiring fiber optical splice closure not only have the butt-joint and branching function, but also have the function of optical cable splitting and wiring, suitable for the installation of main optical cables and drop cables with different diameters.



Features

The closure adopts horizontal mechanical sealing and advanced internal structure design.

It can be installed one 1:8 Cassette PLC splitter.

8 pcs 2*3mm drop cable both ends in and out.

The closure is spacious enough for winding and storing fibers.

The patented sealing structure keep good sealing performance after re-entry and re-using.

Easy open and close of closure without tool.

24cores Fusing Splice available



Applications

Suitable for bunchy fibers

Aerial, wall-mounting

It’s especially applicable to FTTH optical fiber distribution



Specification

Model GJS-2021
Dimension 300*186.5*59mm
Max fusion capacity 24fibers
Max splitter 1pc 1:8 splitter module (LGX)
Cable ports 2in 2out, 8pcs drop cable for 2x3mm in and out
Max. SC adapter 9pcs
Cable diameter Round ports: 4-Φ8~Φ13mm;drop cable ports: 8-2*3mm



Product drawing

LGX Module Fiber Optic Splitter Box Snap On 300 * 186.5 * 59mm For Bunchy Fibers

Standard accessories

LGX Module Fiber Optic Splitter Box Snap On 300 * 186.5 * 59mm For Bunchy Fibers
