FTTH Mechanical SC / UPC Fiber Optic Fast Connector On Site Single Mode

FTTH Mechanical SC / UPC Fiber Optic Fast Connector On Site Single Mode

Products - Field Installable Connector
  • High Light

    quick assembly connector

    ,

    FTTH connector

  • Application
    FTTH On Site Work
  • Connector Type
    SC/UPC
  • Fiber Type
    SMF-28e
  • Cable Type
    Single Mode 9/125um
  • Cable Diameter
    0.9mm
  • Conneector House Color
    Blue
  • Insertion Loss
    Max. <0.5dB, Typical<0.3dB
  • Return Loss
    ≥50dB
  • Place of Origin
    china
  • Brand Name
    YINGDA
  • Certification
    ISO
  • Model Number
    FS-SCU-09-09B
  • Minimum Order Quantity
    100 PCS
  • Price
    Negotiable
  • Packaging Details
    5 pieces or 10pcs / blister box
  • Delivery Time
    5 working days after got payment
  • Payment Terms
    T/T or western Union
  • Supply Ability
    500,000pcs per month

FTTH Mechanical SC / UPC Fiber Optic Fast Connector On Site Single Mode

  • FTTH Mechanical SC / UPC Fiber Optic Fast Connector On Site Single Mode
  • FTTH Mechanical SC / UPC Fiber Optic Fast Connector On Site Single Mode
  • FTTH Mechanical SC / UPC Fiber Optic Fast Connector On Site Single Mode
  • FTTH Mechanical SC / UPC Fiber Optic Fast Connector On Site Single Mode
  • FTTH Mechanical SC / UPC Fiber Optic Fast Connector On Site Single Mode
Get Price Contact Now



FTTH Mechanical SC / UPC Fiber Optic Fast Connector On Site Single Mode



Description



SC Fusion splice-on connector is is optical fiber type quick connector, but its splicing point inside

the connector end, equivalently eliminate the pigtails when splicing.The advantage is no need

additional protection after splice, such as splice tray,splice closure,distribution box. In contract

to the design of mechanical splice connector, it save V-groove mechanical connector aintenance

and operation cost and durable, which overturns the concept that high cost of splice machine

and do not apply to FTTH construction.





Features

  1. Low operation cost, high efficiency
  2. Quickly achieve the on-site termination connection
  3. Easy operation or use
  4. Pressure welding parts adopt new unique structure design, installation without glue injectino,
  5. no grinding,
  6. no consumables
  7. High installation quality, high success rate and installation fast, etc
  8. Easy to carry
  9. Accurate mechanical dimensions
  10. All materials conforms to ROHS



Application

  • FTTH optic fiber terminal connection
  • LAN network
  • Reformation of  ODF and the new patch cord of ODF on site.



Specification



Item

Parameter

Cable

3.1*2.0mm drop cable

Fiber diameter

125um(G657A2 bare fiber)

Tight buffer diameter

250um

Fiber type

Single mode OS1 9/125um

Insertion loss

≤0.3dB

Return loss

≤-50dB

Bare fiber solid tightness

＞250g

Working temperature

-40℃-+80℃

Tensible strength

60N(5kgs for 2mins)

Drop test

4 meters high cement floor direction at a time,in total 3times





Order information

FS-XXX-XX-XXX

         1- 2 -34



FS= fusion

splice

1

2

3

4

Connector type

Fiber inside

Applicable cable

diameter

House color

SCU=SC/UPC

SCA=SC/APC

FCU=FC/UPC

09=0.9mm

25=250um bare fiber

09=0.9mm

20=2.0mm

30=3.0mm

B=blue

B=black

G=green





More photos



FTTH Mechanical SC / UPC Fiber Optic Fast Connector On Site Single Mode 0FTTH Mechanical SC / UPC Fiber Optic Fast Connector On Site Single Mode 1FTTH Mechanical SC / UPC Fiber Optic Fast Connector On Site Single Mode 2FTTH Mechanical SC / UPC Fiber Optic Fast Connector On Site Single Mode 3FTTH Mechanical SC / UPC Fiber Optic Fast Connector On Site Single Mode 4FTTH Mechanical SC / UPC Fiber Optic Fast Connector On Site Single Mode 5



* Please use the customized FTTH melting machine



* Recommended consumable:

Keep a supply of the following items

  • Denatured alcohol
  • Lint-free tissues
  • Cotton swab
Tags:

quick assembly connector

FTTH connector

mechanical splicer
