Waterproof FC / PC Fiber Bundle Pigtail MM 50 / 125um Multimode OS1 SM MM OM1

Waterproof FC / PC Fiber Bundle Pigtail MM 50 / 125um Multimode OS1 SM MM OM1

  • High Light

    optical fiber pigtail

    ,

    waterproof pigtail

  • Connector
    FC/ PC, FC
  • Fiber Count
    12 Cores
  • Insertion Loss
    < 0.3dB
  • Fiber Type
    Multimode 50/125um
  • Package
    Plastic Bag / Bister Box
  • Cable Color
    Blue,pink,purple,orange,yellow,black,red,brown,aqua
  • Strength Member
    900um
  • Jacket
    LSZH, PVC
  • Place of Origin
    china
  • Brand Name
    YINGDA
  • Certification
    ISO SGS ROHS
  • Model Number
    FPC-BF12-OM2-09-03
  • Minimum Order Quantity
    100pcs
  • Price
    negotiable
  • Packaging Details
    1 pc/ box,180pcs / carton box
  • Delivery Time
    7days after payment
  • Payment Terms
    Western Union, T/T
  • Supply Ability
    100,000 pcs per month

Waterproof FC / PC Fiber Bundle Pigtail MM 50 / 125um Multimode OS1 SM MM OM1

FC Fiber Bundle Pigtail MM 50/125um Multimode Fiber 12 Cores, FC Fiber Pigtail





Description



FC/PC Bunchy pigtail, also called FC fiber optic bundle pigtail, only one end has connector

FC, the other end is a fiber cable which is cut off, it is connected with the other fiber core by

fusion, often appear in the optical fiber terminal box to connect the cable and terminal equipment.



It mainly have two types: single mode bunchy pigtails or multi-mode pigtails.Multi-mode (MM)

cable color is orange, wavelength:850nm, transmission distance: 500meters for short connection.





Features

  1. Conforms to ANSI, Bellcore,TIA/EIA,IEC,etc International and domestic standards
  2. Fiber transmission active connection
  3. Low insertion loss, high return loss
  4. Good changeability and repeatability
  5. Mostly used inside frame connection, simple, convenient and economical
  6. Easy to install, small size, large capacity.
  7. Jumper diameters: 2.0mm, 0.9mm.
  8. Fiber count: 4 core 6 core 8 core, 10 core, 12 core.
  9. Fan out fibers have a special tube protection from twisting off or injury,
  10. and good bending properties.
  11. Can use connectors like: FC / PC, FC / APC, SC / PC, SC / APC, ST / PC, etc



Optical Indicators:

  1.   PC   insertion Loss ≤ 0.2dB ; reflection attenuation ≥ 50dB;
  2.    APC insertion loss ≤ 0.2dB ; Return Loss ≥ 60dB

Optical Characteristics



Cable diameter

φ0.9mm, φ2.0mm, φ3.0mm

Insertion loss

≤0.2dB

Return loss

 PC≥40dB,UPC≥50dB,APC≥60dB

Interchange ability test

≤0.2dB

Mating times

>1000 times

Repeat ability

≤0.1dB

Vibration test

≤0.1dB(10-60Hz,1.5mm Full amplitude)

Tensile strength:

0~15Kg

temperature cycling test

≤0.2dB (-40℃~+85℃,after 5times recycle)

Low temperature test

≤0.2dB(-40℃,last 100 hours)

High temperature test

≤0.2dB (+85℃,last 100 hours)

Tensile test

≤0.1dB(0-15Hg tensile,φ0.9mm fiber exception)

Temperature test

≤0.2dB(+25℃~+65℃, relative humidity 93%, after 100hours)





Application

  • CATV network
  • LAN network
  • Fiber Access network
  • Telecommunications
  • Gigabit Data Network test
  • Medical instruments
  • Industry and Army use



Order information



FC fiber optic connector

  1. Polish method: PC UPC APC
  2. Fiber count: 2core, 4core, 6core, 8core, 12 core, etc
  3. Fiber type: G652D, G657A, G657A2, G655
  4. Cable type: OS1 SM, MM OM1, OM2, OM3 10G, OM4,etc
  5. Cable length: 1meter, 2meter, 3meter,.... Etc
  6. Package: Blister box, plastic bag, paper bubble bag
