12 Colors SC APC Fiber Optic Pigtails G657A1 LSZH 900um 3Mts SM Ceramic Ferrule IL<0.2dB

12 Colors SC APC Fiber Optic Pigtails G657A1 LSZH 900um 3Mts SM Ceramic Ferrule IL<0.2dB

  • High Light

    optical fiber pigtail

    ,

    waterproof pigtail

  • Connector
    SC/APC Connector
  • Fiber Count
    12 Cores
  • Insertion Loss
    <0.3 DB
  • Fiber Type
    Single Mode
  • Package
    Plastic Bag / Bister Box
  • Cable Color
    Blue,pink,purple,orange,yellow,black,red,brown,aqua
  • Cable Diameter
    900um
  • Jacket
    LSZH, PVC
  • Connector Color
    Green
  • Temperature
    -40~+85°C
  • Type
    Bundle Pigtails
  • Application
    ODF, Patch Panel, Terminal Box, Cabinet, FOSC
  • Place of Origin
    china
  • Brand Name
    YINGDA
  • Certification
    ISO SGS ROHS
  • Model Number
    YDPG-12SA-030901
  • Minimum Order Quantity
    100pcs
  • Price
    negotiable
  • Packaging Details
    1 pc/ box, 220pcs / carton box
  • Delivery Time
    7days after payment
  • Payment Terms
    Western Union, T/T, L/C
  • Supply Ability
    100,000 pcs per month

12 Colors SC APC Fiber Optic Pigtails G657A1 LSZH 900um 3Mts SM Ceramic Ferrule IL<0.2dB

12 Colors SC APC Fiber Optic Pigtails G657A1 LSZH 900um 3Mts SM Ceramic Ferrule IL<0.2dB





Fiber Optic Bunchy pigtail has connector at one end, the other end is fiber optic cable which be cut off.

Then it connect by splice with other cable core. It is widely used in fiber optic terminal box, ODF rack ,

cabinet to connect with fiber optic media converter/transceivers(also use coupler,patch cord,etc.)



Multimode pigtail is orange, wavelength is 850nm, the transmission distance is 500m, for short distance

interconnects. SMF (single mode fiber ) is yellow, the wavelength:1310nm and 1550nm,the transmission

distance are respectively 10km and 40km.



Optical Characteristics



Cable diameter φ0.9mm, φ2.0mm, φ3.0mm
Insertion loss ≤0.2dB
Return loss PC≥40dB,UPC≥50dB,APC≥60dB
Interchange ability test ≤0.2dB
Mating times >1000 times
Repeat ability ≤0.1dB
Vibration test ≤0.1dB(10-60Hz,1.5mm Full amplitude)
Tensile strength: 0~15Kg
temperature cycling test ≤0.2dB (-40℃~+85℃,after 5times recycle)
Low temperature test ≤0.2dB(-40℃,last 100 hours)
High temperature test ≤0.2dB (+85℃,last 100 hours)
Tensile test ≤0.1dB(0-15Hg tensile,φ0.9mm fiber exception)
Temperature test ≤0.2dB(+25℃~+65℃, relative humidity 93%, after 100hours)
Fiber count 4 core 6 core 8 core, 10 core, 12 core.
Can use connectors

FC / PC, FC / APC, SC / PC, SC / APC, ST / PC, etc



12 Colors Bundle Pigtails Features

  • Individual pacakge: self sealed plastic bag with air vent. Each pigtail is equipped with an English test report.
  • All product will be 100% test in factory before delivery twice, and with low insertion loss, high return loss
  • Conforms to ANSI, Bellcore,TIA/EIA,IEC,etc International and domestic standards
  • OEM or with customer logo on the plastic bag is acceptable.

12 Colors SC APC Fiber Optic Pigtails G657A1 LSZH 900um 3Mts SM Ceramic Ferrule IL<0.2dB 0

  • All use fiber optical ceramic ferrule, angel -8 degree, Concentricity 0.5 or 1, all we use is Three-Circle brand high quality ferrules.
  • Pre-terminated all kinds of connectors such as SC LC ST FC E2000 MU MTRJ DIN D4 SMA MPO MTP, etc.
  • 12 Colors: blue, orange, green, brown, gray, white, red, black, yellow, purple, pink, light blue.

12 Colors SC APC Fiber Optic Pigtails G657A1 LSZH 900um 3Mts SM Ceramic Ferrule IL<0.2dB 1

  • After strip the outer jacket of the distribution cable, fan out fibers have a special tube protection from twisting off or injury, good bending properties.

12 Colors SC APC Fiber Optic Pigtails G657A1 LSZH 900um 3Mts SM Ceramic Ferrule IL<0.2dB 2

  • On the cable circle one side, use a plastic film to wrap the pigtails and the cable together, protect it from mess or break.

12 Colors SC APC Fiber Optic Pigtails G657A1 LSZH 900um 3Mts SM Ceramic Ferrule IL<0.2dB 3

  • On the other side of the circle, nylon rope is used to fix and tie tightly to prevent falling off and confusion during transportation, and it is also convenient for fixation and subsequent use.

12 Colors SC APC Fiber Optic Pigtails G657A1 LSZH 900um 3Mts SM Ceramic Ferrule IL<0.2dB 4





 CABLE TYPE ==== Distribution Tight Buffer Optical Cable(GJFJV)

12 Colors SC APC Fiber Optic Pigtails G657A1 LSZH 900um 3Mts SM Ceramic Ferrule IL<0.2dB 5

Technical Parameters:
Cable Count Outside
Diameter
Tight buffer
Diameter
Weight Minimum allowable Tensile Strength
(N)
minimum allowable Crush Load
(N/100mm)
Minimum Bending Radius
(MM)
Storage
temperature
(MM) (MM) (KG) short term long term short term long term short term long term (℃)
02 3.0 0.9 15.00 600 200 1000 200 20D 10D -20+60
04 4.0 0.9 22.00 600 200 1000 200 20D 10D -20+60
06 4.0 0.9 23.00 600 200 1000 200 20D 10D -20+60
08 5.0 0.9 27.00 600 200 1000 200 20D 10D -20+60
10 5.5 0.9 30.00 600 200 1000 200 20D 10D -20+60
12 6.0 0.9 35.00 600 200 1000 200 20D 10D -20+60



Application

  • Medical instruments
  • Industry and Army use
  • CATV network
  • LAN network
  • Fiber Access network
  • Telecommunications
  • Gigabit Data Network test
