FTTH FIC SC Fusion Splice-on Connector, SC /  PC Field Installable Connector

FTTH FIC SC Fusion Splice-on Connector, SC / PC Field Installable Connector

  • High Light

    quick assembly connector

    ,

    mechanical splicer

  • Application
    FTTH On Site Work
  • Connector Type
    SC/UPC
  • Fiber Type
    SMF-28e
  • Cable Type
    Single Mode 9/125um
  • Cable Diameter
    0.9mm
  • Conneector House Color
    Blue
  • Insertion Loss
    Max. <0.5dB, Typical<0.3dB
  • Return Loss
    ≥50dB
  • Place of Origin
    china
  • Brand Name
    YINGDA
  • Certification
    ISO
  • Model Number
    FS-SCU-09-09B
  • Minimum Order Quantity
    500 PCS
  • Price
    Negotiable
  • Packaging Details
    5 pieces or 10pcs / blister box
  • Delivery Time
    5 working days after got payment
  • Payment Terms
    T/T or western Union
  • Supply Ability
    500,000pcs per month

FTTH FIC SC Fusion Splice-on Connector, SC / PC Field Installable Connector

FTTH FIC SC Fusion Splice-on Connector, SC /  PC Field Installable Connector





Description



SC Fusion splice-on connector is is optical fiber type quick connector, but its splicing point inside

the connector end, equivalently eliminate the pigtails when splicing.The advantage is no need

additional protection after splice, such as splice tray,splice closure,distribution box. In contract

to the design of mechanical splice connector, it save V-groove mechanical connector aintenance

and operation cost and durable, which overturns the concept that high cost of splice machine

and do not apply to FTTH construction.





Features

  1. Low operation cost, high efficiency
  2. Quickly achieve the on-site termination connection
  3. Easy operation or use
  4. Pressure welding parts adopt new unique structure design, installation without glue injectino, no grinding,
  5. no consumables
  6. High installation quality, high success rate and installation fast, etc
  7. Easy to carry
  8. Accurate mechanical dimensions
  9. All materials conforms to ROHS



Application

  • FTTH optic fiber terminal connection



Specification



Item

Parameter

Cable

3.1*2.0mm drop cable

Fiber diameter

125um(G657A2 bare fiber)

Tight buffer diameter

250um

Fiber type

Single mode OS1 9/125um

Insertion loss

≤0.3dB

Return loss

≤-50dB

Bare fiber solid tightness

>250g

Working temperature

-40℃-+80℃

Tensible strength

60N(5kgs for 2mins)

Drop test

4 meters high cement floor direction at a time,in total 3times





Order information

FS-XXX-XX-XXX

         1- 2 -34



FS= fusion

splice

1

2

3

4

Connector type

Fiber inside

Applicable cable

diameter

House color

SCU=SC/UPC

SCA=SC/APC

FCU=FC/UPC

09=0.9mm

25=250um bare fiber

09=0.9mm

20=2.0mm

30=3.0mm

B=blue

B=black

G=green
