DAC Cable
Created with Pixso. 100G QSFP28 To 4x25G SFP28 DAC Twinax Cable Direct Attach Copper Material Compatible With Cisco
100G QSFP28 To 4x25G SFP28 DAC Twinax Cable Direct Attach Copper Material Compatible With Cisco
  • Name
  • Name
  • Name

100G QSFP28 To 4x25G SFP28 DAC Twinax Cable Direct Attach Copper Material Compatible With Cisco

Brand Name: YINGDA
Model Number: RSP-4SFP25G-DAC
MOQ: 1
Price: US$7-20
Delivery Time: 3-7 working days
Payment Terms: D/A,D/P,T/T
Detail Information
Product Description
Detail Information
Place of Origin:
China
Certification:
CE,ISO
Connector:
QSFP28 To 4SFP28
Operating Temperature:
0°C To 70°C
Cable Type:
30/24AWG
Compliance Standards:
RoHS/CE/FCC
Product Type:
Fiber Optic Transceivers
Type:
QSFP28 To SFP28
Data Transfer Rate:
100 Gbps
Distance:
1m 2m 3m 5m
Temp:
0~70
Supply Ability:
1000000per month
Highlight:

100G QSFP28 DAC Twinax Cable

,

4x25G SFP28 DAC Twinax Cable

,

100G QSFP28 To 4x25G SFP28 Cable

Product Description

Description



The 100G QSFP28 to 25G SFP28 high-speed cable is applied in the data center for the 100G (100GBASE-SR4) to 4-channel 25G (25GBASE-SR) Ethernet branch link. At the same time, it is 100% perfectly compatible with all brands of servers, switches, routers, PDH/SDH transmission equipment, EPON, GPON, and WDM PON base stations.



The 100G QSFP28 to 4 SFP28 DAC is suitable for stacking and interconnection of short-distance big data devices. One end is a 100G QSFP28 interface, and the other end has 4 25G SFP28 interfaces. It can provide customers with 100G data transmission and complies with IEEE 802.3BA standard, SFF-8665/SFF-8679, IEEE 802.3bj and Infiniband EDR standards.



Technical Parameter



Product Model RSP-4SFP25G-DAC
Transmission rate 100G
Transmission distance 1-5M (optional)
Packaging form

QSFP28 to SFP28


Cable Type 30AWG/24AWG
Brand YINGDA
Compatible with brand Extreme, Intel, Huawei, Cisco, HP, H3C, etc
Operating temperature 0~70℃
Warranty 3Years
Cable material PVC
Power supply voltage 3.3V





Features

  • Supports hot-swappable QSFP28 and SFP28 packages
  • Complies with QSFP28 MSA, SFP28 MSA, SFF-8636, and SFF-8402 standards
  • Maximum rate up to 103.125 Gbps (4 x 25 Gbit/s)
  • Complies with IEEE 802.3bj 100GBASE-CR4 and 802.3by 25GBASE-CR standards
  • Cable length can be customized within 5 meters
  • Low insertion loss and low crosstalk, etc.
  • Operating temperature: 0 – 70℃
  • Power supply voltage: 3.3V
  • Complies with RoHS 6.0

100G QSFP28 To 4x25G SFP28 DAC Twinax Cable Direct Attach Copper Material Compatible With Cisco 0100G QSFP28 To 4x25G SFP28 DAC Twinax Cable Direct Attach Copper Material Compatible With Cisco 1







Widely  Compatibility


To ensure the compatibility of our products.YINGDA products will be tested on the switch before shipment. Our modules are compatible with many brands of switches, such as Cisco,  Intel...

100G QSFP28 To 4x25G SFP28 DAC Twinax Cable Direct Attach Copper Material Compatible With Cisco 2



Wide Application



25G Ethernet
Data storage and communications industry switches/routers/hba
Enterprise Networking SAN
High Performance Computing Clusters
High-end servers
InfiniBand QDR and Base Station/ BBU/ RRU







More DAC cable for optional

Item# Transmission rate Transmission distance Cable Type Packaging form
SFP-10G-CUxM 10G 1-10M 30/24AWG SFP+ to SFP+
SFP28-25G-CUxM 25G 1-5M 30/26AWG SFP28 to SFP28
QSFP-40G-CUxM 40G 1-7M 30/24AWG QSFP+ to QSFP+
QSFP28-100G-CUxM 100G 1-5M 30/26AWG QSFP28 to QSFP28
QSFP-4x10G-CUxM 40G 1-7M 30/24AWG QSFP+ to 4SFP+
QSFP28-4x25G-CUxM 100G 1-5M 30/26AWG QSFP28 to 4SFP28
