FTTH Optical Fiber One Click LC MU Connector 1.25mm Cleaner Cleaning Pen Type Blue CE ROHS

FTTH Optical Fiber One Click LC MU Connector 1.25mm Cleaner Cleaning Pen Type Blue CE ROHS

  • High Light

    fiber optic tool kits

    ,

    fiber polishing film

  • Color
    Blue
  • Material
    Anti-static Resin
  • Connector
    LC MU
  • Length
    84mm
  • Use Time
    800 Times
  • Application
    Fiber Optic
  • Package
    Gift Box , 1pcs In A Box
  • User Manual
    English
  • Termperature
    -40~+85°C
  • Place of Origin
    china
  • Brand Name
    YINGDA
  • Certification
    ISO CE ROHS
  • Model Number
    CLEP-125
  • Minimum Order Quantity
    50PCS
  • Price
    Negotiable
  • Packaging Details
    1pc/ box, 200 pcs/ carton box
  • Payment Terms
    Western Union, T/T, MoneyGram
  • Supply Ability
    500000PCS a month

FTTH Optical Fiber One Click LC MU Connector 1.25mm Cleaner Cleaning Pen Type Blue CE ROHS

FTTH Optical Fiber One Click LC MU Connector 1.25mm Cleaner Cleaning Pen Type Blue CE ROHS



Fiber Optic Cleaner Pen is designed to specially work well with the female connectors, this instruments cleans the ferrule end faces removing dust, oil, and other debris without or scratching the end face.



LC Cleaner Pen Features

  • Instant cleaning, fast and simple, effectively reduce loss, automatically change cleaning wire to avoid secondary pollution;
  • Cleaning > 800 times, low cost and affordable;
  • Pen design, easy to operate and carry, telecom quality, good adaptability, high efficiency and wide application;
  • The cleaning head can be retracted to avoid not reaching some places;
  • After cleaning, rotate 180°for comprehensive cleaning, and there is a "Kata" prompt sound after cleaning;
  • Effectively remove 99% of stains, and easily remove dust, oil stain and debris on the end face without wiping with alcohol;
  • Use anti-static resin raw materials, safe operation.

LC One Click Cleaner Specification

Part # CLEP-250 CLEP-125
Applicable FC/SC/ST LC/MU
Ferrule type universal 2.5mm universal 1.25mm
Dimension 175*18*18mm 175*18*18mm
Color White blue
Cleaning time 800 times
Material Anti-static resin



Fiber Optic Cleaner Pen Order Information

Part # Connector type Ferrule size Color
CLEP-250 FC/SC/ST Universal 2.5mm White
CLEP-125 LC/MU Universal 1.25mm Blue




FTTH Optical Fiber One Click LC MU Connector 1.25mm Cleaner Cleaning Pen Type Blue CE ROHS 0

FTTH Optical Fiber One Click LC MU Connector 1.25mm Cleaner Cleaning Pen Type Blue CE ROHS 1FTTH Optical Fiber One Click LC MU Connector 1.25mm Cleaner Cleaning Pen Type Blue CE ROHS 2



FTTH Optical Fiber One Click LC MU Connector 1.25mm Cleaner Cleaning Pen Type Blue CE ROHS 3

FTTH Optical Fiber One Click LC MU Connector 1.25mm Cleaner Cleaning Pen Type Blue CE ROHS 4

The Necessity Of Of One-Click End-Face Cleaning Pen

In optical fiber communication, even he dirt or small particles which is invisible to our eyes adhered to the end face of the optical fiber connector may lead to optical signal been cut off, or result in reflection wave for fiber damage, and can even damage the source, make big damage to the whole communication system. Thus, before connection, must clean the optical fiber connectors ferrule (male), adapters (female),or devices.



Brief Introduction Of One-Click End-Face Cleaning Pen

One-Click end face cleaning pen is the innovative design and can replace the cleaning core,it is the most popular fiber cleaning tool, it replace traditional cotton swab + alcohol, when used simply press can clear the attachments on the connector ferrrule,device, modules, it is sustainable use and ensure the best cleaning effect,it is indispensable tool for cable maintenance, widely used in optical network maintenance business, engineering or equipment, device manufacturers, optical fiber end face cleaning pen easily solve the problem of optical fiber adapter ferrule cleaning.



Cost Performance Of One-Click End-Face Cleaning Pen

One-Click optical fiber end face cleaning pen is price low, high performance, good cleaning effect, its price only is 1 / 12 of the Canadian AFC-3000 cleaning gun, cleaning effect is far good than imports professional cleaning cotton. It is now widely used in the domestic optical fiber industry, and it is one of the domestic public recognition of the low price, high performance portable fiber end face cleaner.
