Fiber Optic Patch Panel
Created with Pixso. 2U 19 inch Metal ODF Fiber Optic Patch Panel For FTTH FTTX CATV LAN Data Center
2U 19 inch Metal ODF Fiber Optic Patch Panel For FTTH FTTX CATV LAN Data Center
  • Name
  • Name
  • Name
  • Name
  • Name
  • Name

2U 19 inch Metal ODF Fiber Optic Patch Panel For FTTH FTTX CATV LAN Data Center

Brand Name: YINGDA
Model Number: 24ports ODF
MOQ: 10pc
Price: negotiate
Delivery Time: 5-8days
Payment Terms: D/A, D/P, T/T, Western Union, MoneyGram
Detail Information
Product Description
Detail Information
Place of Origin:
China
Certification:
ISO CE
Application:
FTTH FTTX Telecommunication CATV LAN Data Center
Cable Type:
Simplex Duplex
Fiber Mode:
Single-mode Multi-mode
Material:
Metal
Name:
24 Patch Panel
Size:
19 Inch
Type:
1U Fiber Optic Distribution Panel
Packaging Details:
1pc / box, 5pcs /carton box
Supply Ability:
100000/month
Highlight:

Metal ODF Fiber Optic Patch Panel

,

FTTH ODF Fiber Optic Patch Panel

Product Description



Sliding Out 1U 2U Fiber Patch Panel MODEL

 2U 19 inch Metal ODF Fiber Optic Patch Panel For FTTH FTTX CATV LAN Data Center 0



Sliding Drawer Type Fiber optic patch panel are the auxiliary equipment for terminal wiring in optical fiber transmission communication network, which is suitable for indoor optical cable splice directly and branch connection, and protective the fiber.



48 patch panel Features

  • Applicable in the termination and 19'' standard structure,
  • Rack mount in optical distribution frame ODF
  • Suitable for FC ,SC, ST, LC, E2000 adapters
  • 1.2mm Cold rolled steel sheet, with electrostatic spraying
  • Metal sliding tray of the splice tray and bottom, easy and fast to operate without open the cover
  • Clip cover design, dust proof and whole box closed not in operation
  • Total front operation with cable clamps and routing area, large fiber storage
  • 4 Cable entry ports at back, diameter can be customized, normally 20mm
  • Box color can be customized, white, black,etc.
  • Silk print or laser mark both available.
  • All the metal parts are stainless steel for long life span guarantee.

2U 19 inch Metal ODF Fiber Optic Patch Panel For FTTH FTTX CATV LAN Data Center 1

Box Dimension

Model Dimension(W*D*H)mm Max capacity(cores)
GPSM-1U-SC24 482*300*1U 24
GPSM-1U-FC24 482*300*1U 24
GPSM-1U-2SC24 482*300*1U 48
GPSR-2U-SC48 482*300*1U 48
GPSR-2U-FC48 482*300*2U 48
GPSR-3U-SC96 482*300*3U 96
GPSR-4U-SC144 482*300*4U 144



24 Patch Panel Technical Specification

Width 482 mm
Deepth 300 mm
Height 1U, 2U, 3U, 4U, etc
Max capacity 144 cores
Material 1.2 mm cold rolled steel SPCC
Cable entry port 4 round port with rubber φ20mm
Cable exit port SC FC LC ST E2000, etc adapter port
Adapter quantity 144 pcs
Material coating Powder
Operating temperature -10~+85°C
Standards TIA/EIA 568.C, ISO/IEC 11801, ENS50173, IEC60304, IEC61754, EN297-C, CEA/EIA-310-E, ANSI/TIA/EIA-606-A, GR-449-CORE, RoHS
IP Rating IP20
Color White, black



Connector specification

Insertion loss <0.3dB
Return loss >65dB APC, >50dB UPC, >30dB PC
Mating durability 500 times
Wavelength 850-1550nm
Standards IEC61300, IEC61754, ROHS, etc



Product details

2U 19 inch Metal ODF Fiber Optic Patch Panel For FTTH FTTX CATV LAN Data Center 2







Pack information



Model QTY/CTN (pc) CTN SIZE /cm N.W./CTN (kg) G.W./CTN (kg)
GPSR-1U 5 48.5*42*35 25 27.5
GPSR-2U 4 47*35*55 24.8 26.35
GPSR-3U 3 47*35*45 22.1 23.65
GPSR-4U 2 50*35*54 17.2 18.5



Standard accessory



Item Qty Item Qty
Mounting ears 1pair Heat shrink protection tubes Configuration on request
Number mark Configuration on request Nylon tie Configuration on request
Mounting screws 6pcs Buffer tube 1pc
