1U 19 Inch Sliding Rack Mount Fiber Optic Patch Panel 12 Port LC Duplex Drawer ODF

MOQ: 10 pcs
Price: negotiable
Standard Packaging: 1pc / box, 5 pcs / carton box
Delivery Period: 5-8days after payment
Payment Method: L/C,D/A,D/P,T/T
Supply Capacity: 500,000 pcs per month
Detail Information
Product Description
Ratings & Reviews
Detail Information
Place of Origin
china
Brand Name
YINGDA
Certification
ISO CE
Model Number
GPSM-2LC12
Material:
Cold Rolled Steel
Color:
Black, White
Capacity:
12, 24, 48, 72, 96, 144 Cores
Adapter:
LC Duplex, SC
Cable Ports:
4 Pcs At Back With Rubber Seal
Application:
FTTH FTTX FTTB ODN LAN WAN Network
Dimension:
430*300*1U Or 430*250*1U
Thickness:
1.0mm
Product Name:
1u Patch Panel
Application:
Data Center Rack Cabient
Highlight:

rack mount odf

,

optical distribution frame

Product Description

1U 19 Inch Sliding Rack Mount Fiber Optic Patch Panel 12 Port LC Duplex Drawer ODF




Quick Details of 1U Rack Cabinet

  • 19inch standard rack mount
  • size:480*250*1U or 480*300*1U
  • 12pcs LC duplex adapters
  • max capacity:24cores
  • metal sliding tray to pull out the whole internal panel


Fiber optic patch panel are the auxiliary equipment for terminal wiring in optical fiber transmission communication network,

which is suitable for indoor optical cable splice directly and branch connection, and protective the fiber.

12Port Fiber Optic Patch Panel Features

  1. Applicable in the termination and 19'' standard structure
  2. Metal sliding with rods at both sides for 1U height
  3. Rack mount in optical distribution frame ODF
  4. Suitable for FC,SC,ST,LC,E2000 adapters
  5. Cold rolled steel sheet, with electrostatic spraying

24Core Fiber optic patch panel Specification

Type

Dimension
(mm)

Max capacity
(core)

Carton size
(mm)

Qty/
carton
(pc)

G.w
(kg)

GPSM-1U-SC12

430*300*1U

12

485*420*350

5

29

GPSM-1U-FC24

24

485*420*350

5

29

GPSM-1U-2SC24

48

485*420*350

5

29

GPSM-2U-FC48

430*300*2U

48

500*355*550

4

26.5

GPSM-4U

130*300*4U

192

500*350*540

1

18.9

 1U 19 Inch Sliding Rack Mount Fiber Optic Patch Panel 12 Port LC Duplex Drawer ODF 0

1U 19 Inch Sliding Rack Mount Fiber Optic Patch Panel 12 Port LC Duplex Drawer ODF 1



1U 19 Inch Sliding Rack Mount Fiber Optic Patch Panel 12 Port LC Duplex Drawer ODF 2



Standard accessory:

buffer tube, mounting screws, heatshrink protection sleeve, nylon tie, cable ties, etc.
 1U 19 Inch Sliding Rack Mount Fiber Optic Patch Panel 12 Port LC Duplex Drawer ODF 3


Equivalent ODF'S
We can add the front cable management area for better construction. if customer need.
color: white, black.
1U 19 Inch Sliding Rack Mount Fiber Optic Patch Panel 12 Port LC Duplex Drawer ODF 41U 19 Inch Sliding Rack Mount Fiber Optic Patch Panel 12 Port LC Duplex Drawer ODF 5


Environmental requirements:

  1. Not suitable outdoor use, if need to use, should take protective measures.
  2. Working temperature: -25 to +40 °C
  3. Storage temperature: -25 to +55 °C
  4. Relative humidity: ≤85% (30°C)
  5. Atmospheric pressure: 70 ~ 106kPa
  6. Service life: 20 years

Mechanical properties

  1. Tensile strength:should withstand axial tensile strength not less than 500N between cable
  2.  terminal box and the cable, and not less than 5N between wiring pigtail and terminal box.
  3. Compression test: cable terminal box each should be able to withstand the vertical static
  4. pressure not less than 200N.
  5. Twist test : cable terminal box should be able to withstand the torsion angle.


Electrical properties

  • Fiber optic cable box metal component and cable metal strengthening core, cable metal components and the ground insulation resistance
  • insulation resistance:should be no less than 2*104M ohm, test voltage:500V (DC).
  •  voltage strength: no breakdown, no arc phenomenon at 15Kv DC under 1min, no breakdown, no arc phenomenon.

1U 19 Inch Sliding Rack Mount Fiber Optic Patch Panel 12 Port LC Duplex Drawer ODF 6
