Created with Pixso. 24 Fiber Optical MTP MPO Cable Assemblies OM3 10G Aqua 25 Meter Blue

24 Fiber Optical MTP MPO Cable Assemblies OM3 10G Aqua 25 Meter Blue

Brand Name: YINGDA
MOQ: 200PCS
Price: Negotiable
Delivery Time: 3-5working days after received your payment
Payment Terms: T/T or western Union
Detail Information
Place of Origin:
china
Certification:
ISO
Packaging Details:
Packed in plastic bag, in a shipping outer carton box.
Supply Ability:
40,000pcs per month
Highlight:

MPO fanout cable

,

mpo patch cable

Product Description

12/24 Fiber Optical MPO/MTP Cable assemblies OM3 10G aqua 25meter, 12cores ribbon fiber MPO-MPO patch cord cable

Fiber optic MPO MTP Patch cord cable product description
MPO fiber patch cable is used in current ultra-high-speed network data centers, such as those in databases and network racks. The ultra-high transmission volume is connected as much as possible with the MPO interface to reduce the rack space and arrange the transmission in an orderly manner.

24 Fiber Optical MTP MPO  Cable Assemblies OM3 10G Aqua 25 Meter Blue 0
24 Fiber Optical MTP MPO  Cable Assemblies OM3 10G Aqua 25 Meter Blue 1

One MPO can branch out 12-core LC duplex patch cords, which can save a lot of space. Each patch cord has a clear number mark.



FIber optic MPO cable Features

  • High Performance in IL & RL
  • 4,8,12 and 24fiber connector terminations and assemblies
  • Designed for low loss and standard loss SM and MM applications
  • Economical solution for mass-termination of fiber
  • Suitable for MPO/MTP application
  • Ruggedness round cable, oval cable and bare ribbon options available
  • Color coded housings available to differentiate fiber type, polish type and/or connector grade



MPO fiber optic cables Unique Service:

  1. SAMPLES for quality testing are available
  2. 5 days leading time if order quantity < 100pcs
  3. Drawing, Specification, Test Report  can be sent at any time if request
  4. Quality complaint will handle in 24 hours by our After-sales Service Dept



MPO fiber cable Associated Standards



  1. Meets IEC Standard 61754-7& JIS C5982
  2. Structured cabling per TIA-568-C
  3. Parallel Optics
  4.  - Optical Internet working Forum (OIF) Compliant
  5.  - Infiniband Compliant
  6. Infiniband
  7. - 10G Fiber Channel Compliant
  8. - 40G and 100G IEEE 802.3
  9. - QSFP

fiber optic cable MPO Applications

  • Optical switching inter-frame connections
  • High fiber density card edge access
  • Array trunk cables
  • Data center cabling



fiber optic patch cable MPO Specifications

Fiber type

Singlemode(APC polish)

Multimode(PC/flat polish)

Parameter

Standard

Low loss

Standard

Low loss

Max. IL

<0.7dB

<0.35dB

<0.7dB

<0.35dB

Return loss

>60dB

None

Durability

500matings

Operating temperature

-40°C to 80°C

Test wavelength

1310nm

850nm



More product show:

24 Fiber Optical MTP MPO  Cable Assemblies OM3 10G Aqua 25 Meter Blue 2

Factory workshop:
24 Fiber Optical MTP MPO  Cable Assemblies OM3 10G Aqua 25 Meter Blue 3
24 Fiber Optical MTP MPO  Cable Assemblies OM3 10G Aqua 25 Meter Blue 4

24 Fiber Optical MTP MPO  Cable Assemblies OM3 10G Aqua 25 Meter Blue 5
