MPO APC Male To FC APC Fan Out Cable Single Mode 12 Fiber For High Denstity Application

Name: MPO APC Male To FC APC Fan Out Cable Single Mode 12 Fiber For High Denstity Application
Brand: YINGDA TECHNOLOGY LIMITED
SKU: MTP/M-FC-12F-A202
Price: 49.20 USD
Availability: InStock

Brand Name:	YINGDA
Model Number:	MTP/M-FC-12F-A202
MOQ:	100 pcs
Price:	0.2USD-100USD
Delivery Time:	7days after payment
Payment Terms:	Western Union, T/T

Detail Information

Product Description

Detail Information

Place of Origin:

china

Certification:

ISO CE

Connector:

MPO Male Connector

Fiber Type:

G657A2 Single Mode

Breakout Kit:

Round Black Plastic

Fiber Count:

12 Cores Bundle Cable

Insertion Loss:

<0.7dB

Cable:

Round 3mm Yellow

Operating Temperature:

-20°C~+70°C

Storage Temperature:

-40°C~+80°C

Packaging Details:

1 pc/ box, 160 pcs/carton box

Supply Ability:

10,000 pcs per month

Highlight:

MPO APC Fan out Cable

High Denstity Application MPO Fanout Cable

12 Fiber MPO Fanout Cable

Product Description

12 Fiber MPO APC Male to FC APC Fanout Patch Cord Single Mode 9/125um Breakout Yellow

MPO/MTP fanout assembly are designed for high denstity applicatino with require high performance and speedy installation. MPO/MTP fanout assemblies are numbered for full trace ability.

Available in 12core configuration, these space saving assemblies comes with either MTP male or MTP female connectors on one end and LC SC FC MTRJ connectors on their other end. They are available in lengths are 10 20 30 meters, custom length can be customized. They are available in 4 8 12 fiber ribbon configurations.

Our fiber optic fan-out cable is an excellent choice for high-density applications, featuring a single-mode 12-fiber configuration. It is equipped with MPO APC male and FC APC connectors, ensuring reliable and high-performance data transmission. The cable is made of high-quality materials, with a G.657A2 single-mode fiber type, providing low insertion loss and high return loss. It comes in a round 3mm yellow cable with a round black plastic breakout kit.

Feature of MPO Breakout Cable
* Quick, highly repeatable, low-loss connections
* Simplex & Duples
* Singlemode & Multimode
* PC, UPC & APC polishing
* Various boot (cable) sizes available
* FC/ LC/ SC/ ST/ MTR/ MPO connectors available
* Interferential parameters
* Hybrid patch-cords are available upon request
* Low Insertion loss
* Low PDL
* Excellent channel-to-channel uniformity
* High return loss and Good repeatability
* Wide wavelength range
* Supports 40G and 100G network applications
* Jacket material: 0.9mm cable LSZH, OFNR,

Specification

Parameter	Polishing Connector (A)		Polishing Connector (B)
Polishing Connector	MPO (MM)	MPO APC	SM (SC, LC, FC, MT-RJ)	MM (SC, LC, FC, MT-RJ)
Insertion Loss (IL)	< 0.50 dB	< 0.50 dB	< 0.50 dB	< 0.50 dB
Return Loss (RL)	> 30dB	> 60dB	> 50dB	> 35dB
Mating Cycles Delta IL	< 0.2 dB after 500 mating cycles
Fiber Cable Type	Single mode: G652D or G657A; Multi mode: OM1, OM2, OM3;
Cable Color	Yellow for SM G652 and G657A fiber; Orange for MM OM1 and OM2 fiber; Aqua for MM OM3 fiber;
Cable Jacket	Ribbon / Fan-out (LSZH / PVC)
Patch Cord Pull-out Force	5N
Operating Temperature	-20°C~+70°C
Storage Temperature	-40°C~+80°C

MPO APC Male To FC APC Fan Out Cable Single Mode 12 Fiber For High Denstity Application 0

MPO APC Male To FC APC Fan Out Cable Single Mode 12 Fiber For High Denstity Application 1

MPO APC Male To FC APC Fan Out Cable Single Mode 12 Fiber For High Denstity Application 2

MPO APC Male To FC APC Fan Out Cable Single Mode 12 Fiber For High Denstity Application 3

Product Features:

Connector Performance: The MPO and FC APC connectors offer quick, highly repeatable, and low-loss connections. They support various polishing types such as PC, UPC, and APC, ensuring excellent optical performance.
Versatile Configurations: Available in 12-core configuration, these cables can be customized in length to meet different requirements. They also come in different fiber ribbon configurations like 4, 8, and 12 fibers.
Wide Application Range: Suitable for various applications including telecommunication networks, data centers, supporting SFP, QSFP, CFP applications, 40G to 10G transition, CATV, active device termination, metro networks, local area networks, data processing networks, test equipment, premise installation, and wide area networks.

Bare Fiber Colors

No	8 Ribbon fiber	No	12 Ribbon fiber
1	Blue	1	Blue
2	Orange	2	Orange
3	Green	3	Green
4	Brown	4	Brown
5	Gray	5	Gray
6	White	6	White
7	Red	7	Red
8	Black	8	Black
9	Yellow	9	Yellow
10	Violet	10	Violet
11	Pink	11	Pink
12	Aqua	12	Aqua

Order information

P/N	Description
MPOm-12FC-OM1	MPO Fan-out patch cord, OM1 (62.5/125um), MPO Male-12xFC UPC 1m Orange
MPOm-62FC-OM1	MPO Fan-out patch cord, OM1 (62.5/125um), MPO Male-6xDuplex FC UPC 1m Orange
MPOm-12FC-OM2	MPO Fan-out patch cord, OM2 (50/125um), MPO Male-12xFC UPC 1m Orange
MPOm-62FC-OM2	MPO Fan-out patch cord, OM2 (50/125um), MPO Male-6xDuplex FC UPC 1m Orange
MPOm-12FC-OM3	MPO Fan-out patch cord, OM3 (50/125um), MPO Male-12x FC UPC 1m Orange
MPOm-62FC-OM3	MPO Fan-out patch cord, OM3 (50/125um), MPO Male-6xDuplex FC UPC 1m Orange
MPOm-12FC-OM4	MPO Fan-out patch cord, OM4, MPO Male-12x FC UPC 1m Orange
MPOm-62FC-OM4	MPO Fan-out patch cord, OM4, MPO Male-6xDuplex FC UPC 1m Orange
MPOm-62FC-OM1-U	MPO Fan-out patch cord, OM2 (50/125um), MPO Male-6xDuplex FC UPC 1m Orange uni-boot
MPOm-62SC-OM2-U	MPO Fan-out patch cord, OM1 (62.5/125um), MPO Male-6xDuplex FC UPC 1m Orange uni-boot
MPOm-62FC-OM3-U	MPO Fan-out patch cord, OM3 (50/125um), MPO Male-6xDuplex FC UPC 1m Orange uni-boot
MPOm-62FC-OM4-U	MPO Fan-out patch cord, OM4 MPO Male-6xDuplex FC UPC 1m Orange uni-boot

Application:

Telecommunication networks
Data centers
Supports SFP, QSFP, CFP applications
40G to 10G transition
CATV;
Active device termination;
Telecommunication networks;
Metro;
Local Area Networks;
Data processing networks
Test equipment;
Premise installation;
Wide Area Networks

The reason why Choose us:
1. On time delivery
2. Customization
3. Factory outlet
4. Large product inventory with massive production line
5. China's professional gas detection leader
6. Quality guarantee
7. Product distribution involves multi-fields, dozens of countries including some developed countries.
