Waterproof 8 Ip65 Optical Termination Box Access Terminal FAT

Waterproof 8 Ip65 Optical Termination Box Access Terminal FAT

  • High Light

    fiber optic closure

    ,

    optical distribution box

  • Material
    ABS, PC
  • Color
    White
  • Cable Ports
    3 Pieces
  • Dimension
    199*160*46mm
  • Max Capacity
    8 Fiber SC, 16 Fiber LC Duplex
  • PLC Splitter
    1x2, 1x4, 1x8 Micro Splitter
  • Customer Logo
    Ok
  • Label
    Ok
  • Place of Origin
    china
  • Brand Name
    YINGDA
  • Certification
    ISO,SGS
  • Model Number
    FDB0208D
  • Minimum Order Quantity
    100PCS
  • Packaging Details
    1pc/box,40pcs/carton box
  • Delivery Time
    5-8days after payment
  • Payment Terms
    T/T, Western Union, MoneyGram
  • Supply Ability
    10000PCS/MONTH

Waterproof 8 Ip65 Optical Termination Box Access Terminal FAT

Waterproof 8 Ip65 Optical Termination Box Access Terminal FAT





Model: FDB0208D



This IP65 distribution box offers the ability to terminate 8 fibres housed in a robust ABS enclosure for

indoor and outdoor applications. With the ability to use SC Simplex and LC Duplex adaptor types

offering a flexible solution to the end user, enabling them to incorporate a multi functional enclosure

which allows easy access during installation or re-work with no disturbance of the existing cable or fibres.



In addition to the interchangeable adaptors, the enclosure also offers up to 8 exit points for patching cables and 1 standard cable entry point for loose tube, tight buffer, pre-terminated and steel tape armoured cable.



Each enclosure has integrated strength member tie positions and bend radius protection with the

addition of a removable front cover allowing for quick and easy installation.





Features

  • Up to 8 fibres
  • Removable splice tray for easy installation
  • Multiple adapter options available
  • 8 adapter positions
  • Accepts loose tube, distribution and pre terminated cables
  • Integrated bend radius protection
  • Sealing glands for up to 8 exiting cables + 1 incoming cable
  • Removable cover for ease of installation
  • ROHS, REACH & SvHC compliant
  • Supplied with 8 heatshrink splice protection sleeves
  • Supplied with transit tubing
  • Supplied with wall fixings and tie wraps
  • IP 65



Specifications

Model FDB0208D
Box Size 199*160*46mm
Net weight 0.44kg
Packed weight 0.52kg
Packaged dimensions 215mm x 182mm x 51mm
IP rating IP65
Suitable for adaptor type SC Simplex LC Duplex
Number of fibres 8
Number of ports 3
Material ABS
Colour White
Operating temperature -40°C to +60°C
Designed in accordance with TIA/EIA 568.C, EN50173, IEC60304, IEC61754, EN297-1, ISO/IEC 11801
Compliant to RoHS, Reach/SVHC





1. Adapters installation. There is a buckle to fix the main cable when the cable go through the input.

Waterproof 8 Ip65 Optical Termination Box Access Terminal FAT 0



2. Splice tray
Waterproof 8 Ip65 Optical Termination Box Access Terminal FAT 1Waterproof 8 Ip65 Optical Termination Box Access Terminal FAT 2



3. This splitter box is closed by two buckles as below.

Waterproof 8 Ip65 Optical Termination Box Access Terminal FAT 3Waterproof 8 Ip65 Optical Termination Box Access Terminal FAT 4



Distribution box structure

Waterproof 8 Ip65 Optical Termination Box Access Terminal FAT 5Waterproof 8 Ip65 Optical Termination Box Access Terminal FAT 6Application



  1. Data centres, premise installations, telecommunication networks
  2. Ethernet, Fibre Channel, ATM, LAN, MAN and WAN
  3. Data communication and telecommunication networks
  4. Indoor /outdoor applications





Standard accessories

Waterproof 8 Ip65 Optical Termination Box Access Terminal FAT 7

Packing informations

Model Qty/Carton Box G.W./KGS Size/Carton Box
FDB0208D 40PCS 19.5KGS 75*23*52cm
