24 Port Fiber Splitter Box SC/LC Adaptors Wall/Pole Mount UV/Weather Resistant

MOQ: 100PCS
Price: 1.0USD-18.6USD
Standard Packaging: 1pc in a box, 10 pcs per carton box
Delivery Period: 6days
Payment Method: Western Union, MoneyGram, T/T
Supply Capacity: 5000pcs/month
Detail Information
Product Description
Ratings & Reviews
Detail Information
Place of Origin
china
Brand Name
YINGDA
Certification
ISO,SGS
Model Number
FDB0224A
Material:
ABS+PC
Color:
White
Ftth Drop Cable:
24 Pcs
Cable Ports:
4in 24out
Plc Splitter:
1x2,1x4,1x8,1x16
Adapter:
SC, LC Duplex
Max Splicing:
24 Fibers
Application:
Wall Or Pole Mounting
Customer Logo:
Silk Print
Highlight:

24 Port Fiber Splitter Box

,

SC LC Adaptors Fiber Splitter Box

Product Description



Model: FDB0224A



Fiber Distribution Box is used as a terminal point for the feeder cable to connect with drop cable in telecommunication network system. The fiber splicing, splitting, distribution can be done in this box, and meanwhile it provides protection and management for the FTTx network building.



Features:



  • Anti-UV (Ultraviolet)
  • 4 inlet ports, 24 outlet ports
  • Economic design with plastic adaptor panel
  • Accommodate SC / LC Adaptor
  • Protection Class: IP65



Applications

  • FTTH access network
  • Telecommunication network
  • CATV networks
  • Data communications network
  • Local area networks

Specifications

Model FS-24
Installation Method Wall-mounted or pole-mounted
Color Gray
Material PC+ABS
Adapter Ports (SC) 24 Pcs
Capacity Of Splicing 48 Cores
Cable Ports 4 Ports (For main cable) + 24 Ports (For drop cable)
Size: H×W×D (mm) (Pic 1) 330×270×105









Product dimension:





                               24 Port Fiber Splitter Box SC/LC Adaptors Wall/Pole Mount UV/Weather Resistant 0

Installation

1 Wall-mounted installation

Drill 3 holes in the wall according to the installation size,place the expansion bolt,place the box to match up the holes and use bolt to fasten.



2 Pole-mounted installation

Fix 1 set of the hose clamps to the telecom pole .



24 Port Fiber Splitter Box SC/LC Adaptors Wall/Pole Mount UV/Weather Resistant 1



Packaging information:

Accessories and packing. 1pc/box, 10pcs/carton box.



24 Port Fiber Splitter Box SC/LC Adaptors Wall/Pole Mount UV/Weather Resistant 2



Order information



Model Fiber count PLC split Adapter type Adapter qty Body color Cable port
FDB0224A

01=1fiber

02=2fibers

...

16=16fibers

102=1x2

104=1x4

108=1x8

116=1x16

SCA=SC/APC

SCU=SC/UPC

LCA=LC/APC

LCU=LC/UPC

01=1pc

02=2pcs

03=3pcs

...

16=16pcs

B=Black

W=white

G=gray

A=cable gland

B=uncut cable





Our advantages



1.The most competitive price


2.We are eager to establish long-term cooperation relationship with every customer,so we're responsible for our quality.we provide 3 years warrranty


3.We provide one-stop FTTH Solution Products.besides, we can help you design unique new products and put into production.We care about innovation and would like to change for you and grow up with you.


4.With our own R&D, more completed production lines, advanced production & testing equipments,experienced staffs, we’re confident to provide you satisfied quality and service with competitive price and punctual delivery.


5.For your any queries or inquiries,we will try to reply you within 3 hours



Ratings & Review

Overall Rating

5.0
Based on 50 reviews for this supplier

Rating Snapshot

The following is the distribution of all ratings
5 stars
0%
4 stars
0%
3 stars
0%
2 stars
0%
1 stars
0%

All Reviews

M
M*e
France Nov 19.2024
Helpful (2)
Product was exactly as in pictures with good quality and packing.
S
SC LC Fiber Optic Wall Outlet For Indoor White ABS Material
South Africa Aug 2.2024
Helpful (4)
best price and quality, excellent service
1
1*x
Chile Aug 23.2023
Helpful (9)
Good quality, IP65 waterproof. will continue to cooperate with YINGDA
