2 / 4 Core FTTX Outdoor Fiber Termination Box Wall Mount With PC / ABS Material

Name: 2 / 4 Core FTTX Outdoor Fiber Termination Box Wall Mount With PC / ABS Material
Brand: YINGDA
SKU: FDB6002
Rating: 4.7 (132 reviews)

Brand Name:	YINGDA
Model Number:	FDB6002
MOQ:	100PCS
Price:	NEGOTIABLE
Delivery Time:	5-8 working days
Payment Terms:	Western Union, T/T, L/C

Detail Information

Product Description

Detail Information

Place of Origin:

china

Certification:

ISO SGS CE ROHS

Capacity:

4 Cores

Cable Ports:

2 Pcs (1in,4out)

Dimension:

208×153×52mm

Material:

Polymer Synthetic Plastic

Color:

White

Adapter:

2SC ;4 LC

Installation Method:

Outdoor Wall Mount

Splice Tray:

1 Pc

Feature:

Waterproof

Sealing Method:

Cable Gland And Rubber Circle

Splitter:

1x2 1x4 Mini Module Splitter

Packaging Details:

1 pc per box, 30 pcs per carton shipping box

Highlight:

fiber optic closure

optical distribution box

Product Description

2 / 4 Cores FTTX Outdoor Fiber Optic Terminal Box With PC / ABS Material

Mechanical seal: Excellent sealing performance,reusable. Protection grade is IP 65.

Installation method: Outdoor wall-mounted

Feature:

Professional terminal box is used in FTTH project and receives national patents.
The box is designed to be flipped over with compact size.
It is used to protect optical cable under Φ12, soft cable or Φ3 soft cable.
1:2SC or 1:4LC micro-splitter is applicable;
it also can be installed with SC or LC double cores adaptors.
Maximum of LC adaptor is 4 cores while 2 cores is the maximum for SC adaptor

Specification

Material	Polymer synthetic plastic
Fiber tray capacity	4Core
Dimension	208×153×52mm
Weight	0.5-0.6kg

Pack information

Model	FDB-6002
Carton size	560450275mm
Carton quantity	30pcs
Carton weight	24kgs
