Waterproof 48 Core SC FTTH Fiber Optic Splice Box Size 350*340*120 mm GPDB-S48D

Waterproof 48 Core SC FTTH Fiber Optic Splice Box Size 350*340*120 mm GPDB-S48D
Waterproof 48 Core SC FTTH Fiber Optic Splice Box Size 350*340*120 mm GPDB-S48D Waterproof 48 Core SC FTTH Fiber Optic Splice Box Size 350*340*120 mm GPDB-S48D Waterproof 48 Core SC FTTH Fiber Optic Splice Box Size 350*340*120 mm GPDB-S48D Waterproof 48 Core SC FTTH Fiber Optic Splice Box Size 350*340*120 mm GPDB-S48D Waterproof 48 Core SC FTTH Fiber Optic Splice Box Size 350*340*120 mm GPDB-S48D

Large Image :  Waterproof 48 Core SC FTTH Fiber Optic Splice Box Size 350*340*120 mm GPDB-S48D

Product Details:
Place of Origin: china
Brand Name: YINGDA
Certification: ISO SGS CE ROHS
Model Number: GPDB-S48D
Payment & Shipping Terms:
Minimum Order Quantity: 100PCS
Price: NEGOTIABLE
Packaging Details: 1 pc per box, 6 pcs per carton shipping box
Delivery Time: 5-8 working days
Payment Terms: Western Union, T/T, L/C

Waterproof 48 Core SC FTTH Fiber Optic Splice Box Size 350*340*120 mm GPDB-S48D

Description
Capacity: 48ibers Cable Ports: 12 Pcs
Dimension: 350*340*120mm Material: High Strength Engineer Plastic PC
Color: White Application: FTTH FTTX ODN,PON Network
Adapter: 48 Pcs SC Application: Outdoor Wall Mount, Pole Mount
Splice Tray: 2pcs Each 24 Fibers Feature: Waterproof
High Light:

fiber optic closure

,

splitter distribution box

48 Cores SC FTTH Drop Cable Termination Box Size: 350*340*120 mm







GPDB-S48D plastic waterproof fiber optic cable distribution box are used for the

distribution connection of cable and fiber optic communication devices.

It is suitable for outdoor,corridor or weak current silo or collection points of villas,

for the splicing,storage and distribution of local cable or drop cable, with 48cores capacity.

It leads out the optic signal from drop cable to pigtails by splicing in the box.It can be used

for protective connection of cable and layout pigtails, and fiber optic terminations of optic

access network.





Features:

  1. The box is made of imported flame retardant material,with aging resistant and ultra violet resistant characters;
  2. Sealing with pressed strip,waterproof and dust-proof with IP65;
  3. Special screw and key for its door lock,can be installed on wall or mounted on pole;
  4. Temperature working:-40~+80℃, storage:-40~+80℃.
  5. Spare pigtails and drop cable can be save in the storage part, convenience for maintenance;
  6. Special lock device for outlet of drop cable,  bilayer structure,bottom for splicing and upper layer for splitting and distribution. The installing plate can be turn over for convenience of installation and operation;
  7. 48 positions for adaptors of FC,SC or ST;
  8. Maximum 2 pcs splice tray



Specification



Model

GPDB-S48D

Cable ports

12 pcs

Max capacity

48 core

Dimension

350*340*120mm

Splice tray

24core tray * 2pcs

Adapter

48 pcs SC adaptor simplex

Material

PC





Package information



Model

GPDB-S48D

Carton size

430*380*460mm

Carton quantity

6 pcs

Gross weight of carton

21.8 kgs
