SFP 10G 20km LC/UPC BIDI SFP Module Transceiver Optical Fiber Module

Brand Name:	YINGDA
MOQ:	10pcs
Price:	3.6usd-19.9usd
Delivery Time:	5-7 working days
Payment Terms:	D/A,D/P,T/T

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ISO,CE

Highlight:

10G 20km SFP Module Transceiver

BIDI SFP Module Transceiver

LC/UPC SFP Module Transceiver

Product Description

SFP 10G 20km LC/UPC BIDI SFP Module Transceiver Optical Fiber Module

10G BIDI single fiber bidirectional SFP+ series optical transceiver support a variety of transmission distances from 10Km to 80Km. The series of products use a single LC optical interface, with low power consumption, small size, high reliability, wide temperature range and other characteristics. It is mainly used in SDH/SONET transmission environment.

Features:

Miniature Pluggable Transceiver designed for high performance
SFP Transceiver Module compatible with a wide range of network devices
Small Form-factor Pluggable design for easy installation and replacement
Supports high-speed data transmission with low power consumption
Hot-pluggable interface for seamless integration into existing systems
Reliable and durable construction for long-term use
Compliant with industry standards to ensure broad compatibilityOptical Parameters

Parameter	Symbol	Min.	Typical	Max.	Unit	Note
Transmitter Section
Centre Wavelength	λc	1260	1270	1280	nm	YSP96-B7320
Centre Wavelength	λc	1320	1330	1340	nm	YSP96-B3720
Spectral Width(-20dB)	Δλ			1	nm
Side Mode Suppression Ratio	SMSR	30			dB
Average Optical Power (avg.)	P_out	-3		+3	dBm	1
Laser Off Power	P_off	-	-	-30	dBm
Extinction Ratio	ER	3.5	-	-	dB	2
Relative Intensity Noise	RIN	-	-	-128	dB/Hz
Optical Rise/Fall Time	t_r/ t_f		-	50	ps	3
Optical Return Loss Tolerance		-	-	12	dB
Output Optical Eye	Compliant with IEEE802.3ae eye masks when filtered					2
Receiver Section
Receiver Center Wavelength	λc	1320	1330	1340	nm	YSP96-B7320
Receiver Center Wavelength	λc	1260	1270	1280	nm	YSP96-B3720
Receiver Sensitivity in Average Power	Sen	-14.4		0.5	dBm	4
Los Assert	LOS_A	-30	-	-	dBm
Los Dessert	LOS_D	-	-	-16	dBm
Los Hysteresis	LOS_H	0.5	-	5	dB
Overload	P_in-max	-	-	0.5	dBm	4
Receiver Reflectance		-	-	-12	dB
Receiver Power (damage)		-	-	1.5	dBm

Applications:

◈ 10GBASE-LR/LW Ethernet

◈ 10G Fibre Channel

◈ SONET OC-192/SDH STM-64

FAQ:

Q1: What brand is the SFP Module?

A1: The SFP Module is manufactured by YINGDA, a reputable brand known for quality networking products.

Q2: Does the SFP Module have any certifications?

A2: Yes, the SFP Module is certified with ISO and CE, ensuring it meets international quality and safety standards.

Q3: Where is the SFP Module made?

A3: The SFP Module is made in China.

Q4: What is the minimum order quantity for the SFP Module?

A4: The minimum order quantity is 10 pieces.

Q5: What are the payment terms available for purchasing the SFP Module?

A5: We accept payment via D/A, D/P, and T/T.

Q6: How long does it take to deliver the SFP Module?

A6: The delivery time is typically 5-7 working days.

Q7: What is the price range for the SFP Module?

A7: The price range for the SFP Module is from 3.6 USD to 19.9 USD, depending on the specific model and order quantity.

SFP 10G 20km LC/UPC BIDI SFP Module Transceiver Optical Fiber Module 0

Compatible Brand

We product are compatible with Cisco, 3COM, H3C, HP, aruba, Finisar, Alcatel-Lucent, Allied Telesis, Nortel, Juniper, Huawei,etc.
