Indoor Splitter Module Rack 2 *32 SC1U 19" Distribution Frame Fttx Cabinet 9 / 125 um

Indoor Splitter Module Rack 2 *32 SC1U 19" Distribution Frame Fttx Cabinet 9 / 125 um

  • High Light

    fiber optic splitter

    ,

    fbt coupler

  • Size
    1U Rack 19inch
  • Split Ratio
    2x32 Splitter
  • Connector
    SC Simiplex Adapter
  • Fiber Type
    Single Mode G657A
  • Rack Dimension
    430x250x43mm
  • N.w.
    2.9kgs
  • Rack Color
    Black
  • Material
    Cold rolled steel sheet
  • Place of Origin
    china
  • Brand Name
    YINGDA
  • Certification
    ISO SGS ROHS
  • Model Number
    FSM-232/SC
  • Minimum Order Quantity
    100 pcs
  • Price
    negotiable
  • Packaging Details
    1pc/ box, 5 pcs/carton box
  • Delivery Time
    5-8days after payment
  • Supply Ability
    10,000 pcs per month

Indoor Splitter Module Rack 2 *32 SC1U 19" Distribution Frame Fttx Cabinet 9 / 125 um

Indoor Splitter Module Rack 2 *32 SC 1U 19" Distribution Frame Fttx Cabinet 9/125um





Sell point:

1. cold rolled steel sheet,with electrostatic spraying

2. Metal thickness: 1.0mm not 0.8mm

3. Customer LOGO label or figure number on adapter panel available

4. 1pcs per carton box with plastic film to protect

5. Fast delivery,high quality

6. Productivity: 5000pcs per month

7. Pre-assembly completed loaded available on request



Description

This 1 * 8 plc splitter rack mount patch panel (ODF optical distribution frame) are suitable

 for small capacity optical splitting in FTTH network, achieve optical splitting and distribution

function.This splitter rack module is mainly used in network cabinet or comprehensive cabinet.



Features

  1. Splitting ratio can be customized: 1x2 1x4 1x8 1x16 1x64 2x4 2x8 2x16, etc
  2. Light weight, strong strength
  3. Good anti-shocking and dustproof
  4. Rack dimension can be customized
  5. Asy install
  6. Color: black
  7. Connector: Suitable for FC,SC,ST,LC,E2000 adaptor
  8. Mamterial: Cold rolled steel sheet,with electrostatic spraying
  9. Sheet thickness: 1.0mm
  10. 4cable ports at back



Application

  • Fiber optical communication system
  • CATV system
  • LAN system



Specification



Model

Max PLC splitter ratio

Dimension(W*D*H)mm

Connector

FSM-108/SC

1&1X8 SC

430x250x43

SC/LC/FC

FSM-208/SC

1&2X8 SC

430x250x43

SC/LC/FC

FSM-116/SC

1&2116 SC

430x250x43

SC/LC/FC

FSM-216/SC

1&2X16 SC

430x250x43

SC/LC/FC

FSM-132/SC

1&1X32 SC

430x250x43

SC/LC/FC

FSM-232/SC

1&2X32 SC

430x250x43

SC/LC/FC

FSM-164/SC

1&1X64 SC

430x250x86

SC/LC/FC

FSM-264/SC

1&2X64 SC

430x250x86

SC/LC/FC





Package information



Model

Inner

pack/mm

Inner pack

weight/kg

Carton size

/mm

Carton

weight/kg

Carton

qty/pcs

FSM-1U

465*285*75

2.6

485*425*305

14.2

5

FSM-2U

465*285*125

3.8

675*485*305

21.0

5
