432 / 288 Cores Fiber Optic Splice Joint Closure , In - line Fiber Optic Splice Enclosure

Good quality Fiber Optic Splitter Box for sales
Good quality Fiber Optic Splitter Box for sales
The fiber splitter box so nice. Nice quality, nice package, nice service....Looking forward to our next cooperation :)

—— Antonio

thanks for your fast delivery every time,and sound quality, and every time u offer special support for us. like u company so much

—— Chris Chataika

dear sophie very time ur voice is so sweet and always provide us full solution and fast reply for us, and help us got more and more business, thanks

—— Carla Lo.

am very satisfied with your quality, and you always finish my order on time, hope do more business with you in the future.

—— Benjamin Fernando

I'm Online Chat Now

432 / 288 Cores Fiber Optic Splice Joint Closure , In - line Fiber Optic Splice Enclosure

China 432 / 288 Cores Fiber Optic Splice Joint Closure , In - line Fiber Optic Splice Enclosure supplier
432 / 288 Cores Fiber Optic Splice Joint Closure , In - line Fiber Optic Splice Enclosure supplier 432 / 288 Cores Fiber Optic Splice Joint Closure , In - line Fiber Optic Splice Enclosure supplier 432 / 288 Cores Fiber Optic Splice Joint Closure , In - line Fiber Optic Splice Enclosure supplier 432 / 288 Cores Fiber Optic Splice Joint Closure , In - line Fiber Optic Splice Enclosure supplier

Large Image :  432 / 288 Cores Fiber Optic Splice Joint Closure , In - line Fiber Optic Splice Enclosure

Product Details:

Place of Origin: China
Brand Name: YINGDA
Certification: ISO,SGS
Model Number: H005

Payment & Shipping Terms:

Minimum Order Quantity: 100 PCS
Price: Negotiable
Packaging Details: 1pc / box, 10pcs/ carton box
Delivery Time: 5days after pay
Payment Terms: T/T or western Union
Supply Ability: 50,000pcs per month
Contact Now
Detailed Product Description
Shape: Inline Horizontal Closure Max Capacity: Bunchy: 192 (Cores); Ribbon:  432(Cores)
Cable Port: 3in 3out Cable Diameter: Φ7 - Φ23 Mm
Material: PC Splice Tray Qty: Max. 8 Pcs
Closure Dimension: 450x220x160 Mm Weight: 4 Kgs
Carton Qty: 10pcs Carton Size: 63*52*50mm

432 / 288 Cores Fiber Optic Splice Joint Closure,3in 3Out In-line Optical Enclosure





The closure casing is made of quality engineering plastics, and of good performance of anti-erosion

against acid and alkali salt, anti-aging, as well as smooth appearance and reliable mechanical structure.



The mechanical  structure is reliable and has the performance of resisting wild environment and

intensive climate changes and  serious working environment. The protection grade reaches IP68.



The closures are applicable to ribbon type optical cable and common optical cable. The splice trays

inside the closure are turnable like booklets, and have adequate curvature radius and space for

winding optical fiber to make sure the curvature radius for optical winding 40mm.Each optical cable

and fiber can be operated individually.



The closure is of small volume, big capacity and convenient maintenance.



The elastic rubber seal rings inside the closure are of good sealing and sweat-proof performance.



The casing can  be opened repeatedly without air leakage. No special tools are required.

The operation is easy and simple.The air  valve is provided for the closure and used to check the

sealing performance.



Sell point:

  1. Dimension (L×W×H): 450×220×160 mm
  2. Cable ports:6 ports / 3in 3out
  3. Cable Diameter: Max φ23
  4. Max.Capacity (bunchy fiber): 192
  5. Core capacity per tray: 12 or 24
  6. Holds up to 192 fibers.



 Features

  • Easy to re-enter
  • Cable entry/exit ports
  • Pressure testing valve and earth deriving device
  • Intergrated seal, air tight and water proof
  • Ideal for cable repair
  • RoHS compliant
  • Can be used in through, branch or mid span splice locations



Application:

  •  aerial, underground, pipeline, handhole.



The ambient temperature ranges from -40 to 65℃.





Specification



Outside dimension (LxWxH)

450x220x110 (mm)

Weight (excluding outside box)

2750g-3200g

Number of inlet/outlet ports

3 (pieces) on each side (total 6 pieces)

Diameter of fiber cable

Φ8—Φ23 (mm)

Capacity of FOSC

Bunchy: 6—96 (Cores)

Ribbon: max. 216 (Cores)

Splice tray

Max. 4pcs

Splice tray capacity

Bunchy:6,12,24cores;Ribbon:3,6 pieces

Insert plate size

175x56x30(mm)

Body size

378x136 (mm)





Accessory List





No.

Name of accessories

Usage

1

Heat shrinkable

protective sleeve

Protecting fiber splices

2

Nylon tie

Fixing fiber with protective coat

3

Insulation tape

Enlarging diameter of fiber cable for easy fixing

4

Seal tape

Enlarging diameter of fiber  cable which fits in with seal fitting

5

Hanging hook

For aerial use

6

Earthing wire

Putting through between earthing devices

7

Abrasive cloth

Scratching fiber cable

8

Labeling paper

Labeling fiber

9

Special wrench

Fixing bolts, tightening nut of reinforced core

10

Measuring paper

To measure circle, of which its diameter is enlarged with seal tape

11

Buffer tube

Hitched to fibers and fixed with FOST, managing buffer

12

Desiccant

Put into FOSC before sealing for desiccating air.
