24 Ports Fiber Access Terminal Box with SC/UPC adapter Pigtails , 1*8 1*16 Splitter Distribution Box White

China 24 Ports Fiber Access Terminal Box with SC/UPC adapter Pigtails , 1*8 1*16 Splitter Distribution Box White supplier
24 Ports Fiber Access Terminal Box with SC/UPC adapter Pigtails , 1*8 1*16 Splitter Distribution Box White supplier 24 Ports Fiber Access Terminal Box with SC/UPC adapter Pigtails , 1*8 1*16 Splitter Distribution Box White supplier 24 Ports Fiber Access Terminal Box with SC/UPC adapter Pigtails , 1*8 1*16 Splitter Distribution Box White supplier 24 Ports Fiber Access Terminal Box with SC/UPC adapter Pigtails , 1*8 1*16 Splitter Distribution Box White supplier 24 Ports Fiber Access Terminal Box with SC/UPC adapter Pigtails , 1*8 1*16 Splitter Distribution Box White supplier

Large Image :  24 Ports Fiber Access Terminal Box with SC/UPC adapter Pigtails , 1*8 1*16 Splitter Distribution Box White

Product Details:

Place of Origin: CHINA
Brand Name: YINGDA
Certification: ISO
Model Number: FDB0224H

Payment & Shipping Terms:

Minimum Order Quantity: 100pcs
Price: negotiable
Packaging Details: 1PC/BOX,10PCS/CARTON
Delivery Time: 1week
Payment Terms: T/T, Western Union
Supply Ability: 100k per month
Contact Now
Detailed Product Description
Color: White Material: PC+ABS
Protection Grade: IP66 Cable Ports: 2in, 24out
Max Capacity: 24 Fibers Splitter Type: 1*4, 1*8,1*16 Micro Splitter

24 Ports Fiber Access Terminal Box with SC/UPC adapter Pigtails, 1*8 1*16 Splitter Distribution Box White





YINGDA fiber access termination box is able to hold up to 24 subscribers. It is used as a termination

point for the feeder cable to connect with drop cable in FTTx network system. It integrates fiber splicing,

splitting, distribution, storage and cable connection in one solid protection box.



Features

Waterproof design and with IP-66 protection level

Integrated with splice cassette and cable management rods.

Manage fibers in a reasonable fiber radius condition

Easy to maintain and extend the capacity

Fiber bend radiuscontrol more than 40mm

Suitable for the fusion splice or mechanical splice

1*16 splitter can be installed as an option

Efficient cable management

24 ports cable entrance for drop cable



Configuration



Dimension Max capacity Weight Color Material
340*250*110 SC 24 ports PLC 1X16 (SC) 1.5kgs Black/white PC+aBS



24 Ports Fiber Access Terminal Box with SC/UPC adapter Pigtails , 1*8 1*16 Splitter Distribution Box White24 Ports Fiber Access Terminal Box with SC/UPC adapter Pigtails , 1*8 1*16 Splitter Distribution Box White

   2 Ports Cable Entry, 24 Ports Out Cable                               Wall Mount / Pole Mount



24 Ports Fiber Access Terminal Box with SC/UPC adapter Pigtails , 1*8 1*16 Splitter Distribution Box White24 Ports Fiber Access Terminal Box with SC/UPC adapter Pigtails , 1*8 1*16 Splitter Distribution Box White

    Upper layer for adapter and fiber storage           Down layer for fiber fusion, splitter and storage



24 Ports Fiber Access Terminal Box with SC/UPC adapter Pigtails , 1*8 1*16 Splitter Distribution Box White24 Ports Fiber Access Terminal Box with SC/UPC adapter Pigtails , 1*8 1*16 Splitter Distribution Box White

                    24pcs SC adaptr panel                                   fiber management with wire rings





Standard accessories



Splice cassette, cable management tool, installation nuts and bolts, protection sleeve, hose clamp,rubber seal for cable entrance



Optional accessories



Pole ring, extra lock and key
